5-Axis CNC Machined Stainless Steel Valve Body
Fully machined stainless steel valve bodies produced on 5-axis CNC machining centers, enabling complex internal flow passages, angled port intersections, and contoured surfaces to be completed in a single setup. Suitable for high-pressure hydraulic valves, process control valves, and instrumentation valve bodies. Available in 304, 316/316L, 2205 duplex, and 17-4PH with optional surface grinding and electropolishing. Max envelope 600 × 500 × 400 mm.
Manufacturing Processes :
CNC turning (multi-axis with live tooling), CNC milling (3/4/5-axis), cylindrical grinding, centerless grinding, honing, thread cutting, broaching, drilling & tapping, EDM wire-cut (partner)Heat Treatment :
Quench & temper | Case hardening / carburizing | Induction hardening | Solution annealing | Vacuum hardening | Nitriding | Stress relieving. Every heat treatment batch ships with time–temperature chart and hardness report.Surface Treatment :
Zinc plating (clear/yellow passivation) | Zinc-nickel alloy | Electroless nickel | Hard chrome plating | Black oxide | Phosphating (MnPO4) | Passivation (ASTM A967) | Electropolishing | Anodizing (aluminum) | Powder coatingCustomizable :
YesOrder(MOQ) :
Prototype: 1–10 pcs (no MOQ for billet-machined parts). Small batch: 10–500 pcs. Series production: 500–50,000+ pcs/month.Specifications
Shengtao's 5-axis CNC machined stainless steel valve bodies are produced on advanced 5-axis machining centers that tilt and rotate the workpiece continuously while the spindle cuts, enabling complex internal flow passages, angled port intersections, contoured outer surfaces, and compound-angle sealing faces to be completed in a single setup without transferring the part between fixtures. This single-setup philosophy is the critical advantage of 5-axis machining for valve bodies: every port, bore, thread, and sealing surface shares a common datum, so port-to-port positioning tolerance is held to ±0.05 mm regardless of how many ports the body has or what angles they exit at, eliminating the cumulative alignment errors that would otherwise require expensive post-machining inspection and rework.
Stainless steel is the material of choice for valve bodies operating in corrosive media, high-pressure hydraulic systems, and hygienic process environments. 304 provides general corrosion resistance for industrial water and mild chemical service. 316/316L is specified for chloride-containing fluids, marine environments, and chemical processing where pitting resistance is essential. Duplex 2205 delivers roughly double the yield strength of 316 combined with excellent chloride stress-corrosion cracking resistance, making it the preferred grade for subsea and offshore valve bodies where weight savings and pressure ratings intersect. 17-4PH precipitation-hardening stainless is selected when the valve body must withstand high mechanical loads at elevated temperatures. All material is supplied with EN 10204 3.1 mill test reports, and heat number traceability is maintained through machining, heat treatment, and final inspection.
Internal flow passages are drilled, bored, and reamed to produce clean, burr-free surfaces that minimize flow restriction and turbulence. Threads are single-point milled rather than tapped on 5-axis machines, which produces stronger, more accurate threads with perfect alignment to the port axis. Sealing features — O-ring glands per ISO 3601, cone seats for metal-to-metal seals, and flat-face seats for bonded seal washers — are machined to surface finish and dimensional tolerances that ensure reliable, leak-free assembly at rated pressure. Each valve body is 100% dimensionally inspected on CMM, with threads gauge-checked and PMI-verified for material grade confirmation. Contact us with your valve body drawing or 3D model for a quotation within 24 hours.
5-Axis CNC Machined Stainless Steel Valve Body is one of our core strength products. We maintain substantial inventory to ensure rapid delivery and can also customize extra-large diameter seamless pipes according to your specific requirements. Additionally, we provide comprehensive services including spectroscopic analysis, mechanical property testing, pressure testing, and non-destructive testing (NDT).
|
Note: If you do not find a 5-Axis CNC Machined Stainless Steel Valve Body that meets your requirements or is suitable for your customer’s project, please contact our manager sales consultant (Email: stsalesman4@stmetal001.com) and send us your specifications and technical parameter files to obtain Customized quotation plan. |
